Data Transmission
Quick test results transmission (WIFI, LAN and Bluetooth) enables healthcare professionals to quickly make treatment decisions and adjust therapy as needed, which can improve patient outcomes
Improved Integration
The meter system can be integrated with EMR / HIS / LIS, enabling seamless data exchange and enhancing the Point-of-Care data availability and management
Login Authorization
Login authorization can help improve data security, account-ability, and compliance, which are all critical aspects of providing high-quality patient care
| Measurement principle | Electrochemical detection technique | Screen | 4.5-inch color touch screen |
| Measurement range | 10 - 600 mg/dL (0.6 - 33.3 mmol/L) | Barcode scanner | Infrared barcode scanner |
| Enzyme | Glucose dehydrogenase(GDH-FAD) Glucose oxidase(GOD) |
Battery | 2300mAh rechargeable lithium battery(4.5hrs to full charge) |
| Sample volume | About 0.5μL | Battery life | 100 tests |
| Test time | About 5 seconds | Input voltage | 9V DC |
| Hematocrit range | VivaChek™ Ino:20-70% Vivachek™ Fad:0-70% |
Input frequency | DC |
| Calibration | Plasma equivalent | Input current | 2A(max) |
| Sample type | VivaChek™ Ino:Fresh whole blood(capillary blood) VivaChek™ Fad:Fresh whole blood (capillary blood, venous blood, arterial blood) |
Dimension | 158.4x73.2x21.2 mm |
| Operation temperature | 5 - 45°C | Weight | 150g(without docking unit) |
| Operation humidity | 10% - 90% | Data transfer | WiFi, LAN & Bluetooth |
| Memory | 8G(3,000 patients/ 50,000 tests/ 2,000 QC tests/ 1,000 operators) | Strip ejector | Yes |
| Glucose(GDH-FAD) | Glucose(GOD) | Ketone | Uric Acid | |
|---|---|---|---|---|
| Measurement Range | 10-600 mg/dL (0.6-33.3 mmol/L) |
10-600 mg/dL (0.6-33.3 mmol/L) |
0.1-8.0 mmol/L | 170-1190 μmol/L (2.86-20 mg/dL) |
| Testing Method | Electrochemical Biosensor | Electrochemical Biosensor | Electrochemical Biosensor | Electrochemical Biosensor |
| Coding | Auto-coding | Auto-coding | Auto-coding | Code strip |
| Test Time | 5s | 5s | 10s | 6s |
| Sample Volume | 0.5 μL | 0.5 μL | 0.8 μL | 1.5 μL |
| Sample Type | Fresh Whole Blood (capillary, venous, arterial, neonatal) |
Fresh Whole Blood (capillary) |
Fresh Whole Blood (capillary, venous) |
Fresh Whole Blood (capillary, venous) |
| Hematocrit Range | 0-70% | 20-70% | 20-65% | 10-70% |
| Strip Storage Temperature | 2-30℃ | 2-30℃ | 2-30°c | 2-30℃ |
| Strip Operation Temperature | 5-45℃ | 5-45℃ | 7.5-45℃ | 10-40℃ |
| Strip Shelf-life (unopened) | 24 months | 24 months | 24 months | 24 months |
