|Laboratory Automation Preprocessing System

The Solution



Intelligent Blood Collection Station (Customized)

• Workstation: double-faced machine to serve 2 seats.
• Contents:

• concealed Samples Deliver Port
• Sharp tool deliver port
• Medical waste deliver port
• Storage drawers

• Built-in sample transportation track to connect to Sorting Module or PTS transportation system.
• Single-use blood collection pad, no carryover pollution

•



Intelligent Blood Collection Station (Customized)

Sample Tube Preparation Module

• Rapidly choose tube, print and post label, no manual intervention required, simplify workflow.
• Disordered load sample tube, bulk feed.
• 6 vacutainer stock bins, 100 tubes/bin, total capacity up to 600 tubes
• For emergency, available to print label by external printer and post label manually
• Normalized label post, improve the quality, raise barcode identification rate
• 3.5 s/tube to response the order, stable and efficient

•





PTS Sender

• Core control panel, control and supervise the sender.
• Efficiency up to 800 tubes/hour
• In 1000m,  no speed down
• 7-9m/s, up to 600m/min.
• Cache capacity: up to 500 tubes
• Load types: connect to Intelligent Blood Collection workstation, sorting module, bulk input mode and single tube load.
• Floor standing type, less footprint
• Emergency input port: support queue jumping, error -preventing random input
• Available to deliver Φ12-18mm, length 80-110 (with cap) vacuum collection tube (for example: 13*75mm, 13*100mm)

•



PTS Pipeline System

• Φ 25 mm, point-to-point transportation
• 13*75mm, 13*100mm vacuum blood collection tube are available to transfer
• Easy to install, suitable for any new or old buildings
• Abrasion-proof and good ductility, ensure stable and safe  when transport samples
• Visual transportation, the tubes can be sent visually
• Fully sealed transportation pipeline, avoiding sample lose and biological pollution
• Easy to clean and maintain the pipeline, one click to complete
• Customize the deceleration and speed pressure controlling solution, 0 effect on sample quality
• service life 50 years, fire rating is GRADE B, fire-retardant.
• Pipeline clean & maintenance cycle: Each 30,000tubes/6 months

•
