Full Walk Away Hematology Solution for Small Mid-Size Laboratories
The Yumizen H550 is a compact 6-Diff hematology analyzer with an auto sampling system which aims at providing a full walk away capability to a variety of clinical environments: hospitals, satellite labs, emergency care, small independent labs, doctors’ offices…
With safe sample management, the Yumzien H550 is able to deliver a one hour autonomy of 40 samples in racks. Additional benefits include; continuous loading, automatic sample mixing, positive identification of samples and a manual mode for STAT samples for both open and closed tubes. The latter will manage emergency and pediatrics demands for a variety of samples types.
Based on the innovative ‘3 reagent use’ technology with low consumption, the Yumizen H550 hematology system incorporates enhanced features with high added value for laboratories in terms of data management and traceability standards: flexible connectivity with both ASTM and HL7 communication standards and overlapping Quality Controls.
|
Weight |
77 lbs / 36 kg |
|
Power supply |
100 to 240 V ( 10%), 50 to 60 Hz |
|
Dimensions |
24 x 20 x 26 in / 62 x 53 x 67 cm (HxWxD). |
|
Printer |
Compatible models with Linux drivers |
|
Throughout |
60 tests/hour |
|
Screen |
Colour LCD touch screen of 12.1 in |
|
Data management |
LinuxTM Transmit patient & QC to LIS
Uni-directional or bi-directional connection Communication Protocols: ASTM & HL7 Connection: RS232, Ethernet, USB
|
|
Memory |
10,000 results + Graphics 3 controls level (low, normal, high) Target values download (USB) |
|
Quality Control Management
|
Overlapping QC Levey-Jennings Graphs Radar Graphs XB on 3 or 9 parameters Compatible with QCP |
|
Logs |
Reagents, calibration, quality control, blank cycle, users, settings, service, communication |
|
Parameters (27) |
WBC, NEU# & NEU%, LYM# & LYM%, MON# & MON%, EOS# & EOS%, BAS# & BAS %, LIC# & LIC%*, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD*, PLT, MPV, PCT*, PDW*, P-LCC*, P-LCR* |
|
Graphs |
High-definition Diff matrix PLT & RBC curves |
|
Sample-Volume |
CBC mode : 20 µL DIFF mode: 20 µL |
|
Stability |
48 hours post-draw stability for CBC parameters, 24 hours post-draw stability for DIFF parameters |
|
Operating sample mode |
Automtic mode (rack) and manual mode (STAT samples) |
|
Identification |
Alphanumeric. Bar-code reader (optional) |
* RUO parameters (Research Use Only)
|
Parameters |
Presicion (% CV) |
Linearity |
|---|---|---|
|
WBC |
< 3.0 |
0-300 109/L |
|
RBC |
< 2.0 |
0-8 1012/L |
|
HGB |
< 1.5 |
0-240 g/L |
|
HCT |
< 2.0 |
0.67 L/L |
|
PLT (whole blood) |
< 5.0 |
0-2500 109/L |
|
PLT (PLT concentrate) |
< 5.0 |
0-4000 109/L |
